Anycubic Photon Mono 4 3D Printer
Anycubic Photon Mono 4 is a modern resin 3D printer designed for accurate LCD MSLA printing. The printer is equipped with a 7″ monochrome LCD screen with 10K resolution 9024 x 5120 px, which helps produce sharp details, clean edges, fine lines and smooth model surfaces. With 17 x 17 micron XY precision, this printer is a strong choice for miniatures, figures, jewelry master models, dental models, prototypes, decorative parts and small technical components.
Anycubic Photon Mono 4 is made for users who need a compact, precise and easy to use resin 3D printer for home, studio or workshop use. The build volume of 153.4 x 87 x 165 mm provides enough space for most everyday resin printing tasks, while compatibility with 405 nm photopolymer resins makes the printer suitable for hobby projects, model making, prototyping, education and professional applications.
Main advantages of Anycubic Photon Mono 4
- 7″ monochrome LCD screen with 10K resolution 9024 x 5120 px
- High detail quality with 17 x 17 micron XY precision
- Build volume 153.4 x 87 x 165 mm
- Printing speed up to 70 mm/h with high speed resin
- Upgraded parallel matrix light source
- Compatible with popular 405 nm photopolymer resins
- Laser engraved build platform for better first layer adhesion
- FEP film in the resin vat
- Manual 4 point platform leveling
- Power loss resume support
- 2.8″ touch screen control
- USB file transfer
Technical specifications of Anycubic Photon Mono 4
| Printer type | Resin MSLA 3D printer |
| Model | Anycubic Photon Mono 4 |
| Printing screen | 7″ monochrome LCD |
| Screen resolution | 10K 9024 x 5120 px |
| XY precision | 17 x 17 microns |
| Build volume | 153.4 x 87 x 165 mm |
| Printing volume | 2.2 L |
| Printing speed | Up to 70 mm/h with high speed resin |
| Layer height range | 0.03 to 0.15 mm |
| Light source | Parallel Matrix Upgrade Light Source |
| Light intensity | About 3000 uW/cm2 |
| Build platform | Laser engraved build platform |
| Z axis | Single linear rail with 30 micron precision |
| Vat film | FEP Film |
| Resin vat capacity | Up to 0.39 L |
| Leveling | Manual 4 point leveling |
| Power loss resume | Supported |
| Screen protector | Replaceable scratch resistant film |
| Automatic resin feeding | Not supported |
| Heated resin vat | Not supported |
| Slicer | Anycubic Photon Workshop |
| File transfer | USB |
| Control screen | 2.8″ touch screen |
| Printer weight | 4 kg |
| Printer size | 230 x 235 x 391 mm |
| Package weight | 5.7 kg |
| Package size | 480 x 300 x 300 mm |
Applications for Anycubic Photon Mono 4
- Highly detailed miniatures and figures
- Small prototypes and engineering parts
- Master models for casting
- Jewelry models and decorative elements
- Dental and orthodontic models with suitable resins
- Hobby projects, model making, tabletop gaming and collectibles
- Detailed housings, mounts, mockups and design parts
Compatible materials
Anycubic Photon Mono 4 works with a wide range of 405 nm photopolymer resins. Standard resin is suitable for everyday printing. ABS like resin and tough resin are better for stronger functional parts. High speed resin can be used for faster printing. Water washable resin is convenient for easier cleaning. Plant based resin is a good choice for users who prefer a lower odor and more eco focused material option.
- Standard Resin
- Standard Resin V2
- Water Wash Resin
- Water Wash Resin Plus
- ABS Like Resin
- ABS Like Resin V2
- ABS Like Resin Pro 2
- High Speed Resin
- Plant Based Resin
- Tough Resin
- High Clear Resin
- DLP Craftsman Resin
- Bio Resin
Usage recommendations
- Shake or mix the photopolymer resin well before printing.
- Place the printer on a flat and stable surface.
- Check build platform leveling before the first print.
- Use a screen protector to protect the LCD from resin leaks and scratches.
- After printing, wash the model in alcohol or water depending on the resin type.
- After washing, complete the final UV curing process.
- Store resin in a closed bottle away from direct sunlight.
- Work with resin while wearing gloves and use the printer in a well ventilated area.
Why choose Anycubic Photon Mono 4
Anycubic Photon Mono 4 is a practical choice for users who want a modern resin 3D printer with high resolution, compact size and simple operation. The 10K screen and 17 micron XY precision make this model especially useful for miniatures, decorative objects, prototypes and accurate small models. The printer takes little space, uses USB file transfer and is suitable both for beginners and for regular resin printing in a workshop.
FAQ
Is Anycubic Photon Mono 4 suitable for beginners?
Yes. The printer has a clear structure, manual 4 point leveling, touch screen control and works with Anycubic Photon Workshop.
What resolution does Anycubic Photon Mono 4 have?
The printer has a 7″ monochrome LCD screen with 10K resolution 9024 x 5120 px.
What is the print precision of Anycubic Photon Mono 4?
The XY precision is 17 x 17 microns, which allows the printer to produce small details and complex geometry.
What is the build volume of Anycubic Photon Mono 4?
The build volume is 153.4 x 87 x 165 mm.
What film is used in the resin vat?
Anycubic Photon Mono 4 uses FEP Film in the resin vat.
Does Anycubic Photon Mono 4 support automatic resin feeding?
No. Automatic resin feeding is not supported in this model.
Can I use water washable resin?
Yes. The printer is compatible with water washable resin and other popular 405 nm photopolymer resins.
What is the maximum printing speed?
The maximum printing speed can reach up to 70 mm/h when using high speed resin.
