Anycubic Photon Mono M7 Max 3D Printer
Anycubic Photon Mono M7 Max is a large format resin 3D printer designed for big models, batch printing and accurate UV resin production. The printer features a 13.6″ monochrome LCD screen with 7K resolution, LighTurbo 3.0 optical system, Improved ACF Film, automatic resin feeding and dynamic resin vat temperature control. It is made for users who need a large build area, stable printing performance and high productivity with photopolymer materials.
The main advantage of Anycubic Photon Mono M7 Max is its 14.7 L print volume and 298 x 164 x 300 mm build area. This format allows users to print large prototypes, architectural models, decorative objects, housings, master models, dental models, engineering parts and multiple smaller components in one print cycle. The printer is suitable for workshops, 3D printing studios, small production, design offices and professional resin printing workflows.
Main advantages of Anycubic Photon Mono M7 Max
- 13.6″ monochrome LCD screen with 7K resolution
- Large build area of 298 x 164 x 300 mm
- Ultra large 14.7 L print volume
- X/Y resolution of 46 x 46 microns
- Printing speed up to 86 mm/h with High Speed Resin at 0.1 mm layer height
- Printing speed up to 63 mm/h with Standard Resin at 0.1 mm layer height
- COB Light Source plus Fresnel Lens plus Light Uniformity Algorithm
- Light intensity of 4500 plus or minus 10% uW/cm2
- Improved ACF Film for faster model release
- Dual linear rails on the Z axis with 10 micron precision
- Laser engraved aluminum build plate
- Resin vat up to 1.3 L with unibody design and scale markings
- Automatic resin feeding support
- Resin auto recycling management
- Dynamic resin vat temperature control from 20 to 40 °C
- Manual 4 point leveling
- Power loss resume support
- Replaceable scratch resistant screen protection film
- Anycubic App support
- 4.3″ touch control screen
Technical specifications of Anycubic Photon Mono M7 Max
| Printer type | Resin MSLA 3D printer |
| Model | Anycubic Photon Mono M7 Max |
| Printing screen | 13.6″ monochrome LCD |
| Screen resolution | 7K |
| X/Y axis resolution | 46 x 46 microns |
| Build volume | 298 x 164 x 300 mm |
| Printing volume | 14.7 L |
| Printing speed | Up to 31 mm/h with Standard Resin at 0.05 mm layer height, up to 63 mm/h with Standard Resin at 0.1 mm layer height, up to 86 mm/h with High Speed Resin at 0.1 mm layer height |
| Maximum layer speed | Up to 4 seconds per layer at 0.05 mm layer height |
| Layer height range | 0.01 to 0.15 mm |
| Light source | COB Light Source plus Fresnel Lens plus Light Uniformity Algorithm |
| Light intensity | 4500 plus or minus 10% uW/cm2 |
| Material compatibility | High speed resin, water washable resin, standard resin, ABS like resin, plant based resin |
| Build platform | Laser engraved aluminum build plate |
| Z axis | Dual linear rails with 10 micron precision |
| Release film | Improved ACF Film |
| Resin vat capacity | Up to 1.3 L, unibody design with scale markings |
| Machine leveling | Manual 4 point leveling |
| Power loss resume | Supported |
| Power supply | 180 W |
| Protection film | Replaceable scratch resistant film |
| Resin auto fill unit | Supported |
| Dynamic temperature control resin vat | Supported |
| Temperature control range | 20 to 40 °C |
| Slicing software | Photon Workshop, Chitubox, Lychee Slicer Scheduled |
| File transfer | USB, WiFi, LAN Scheduled |
| Cover | UV blocking hinged cover with one hand operation support |
| Operating screen | 4.3″ Touch Control |
| Air purifier | Optional accessory |
| Anycubic App | Supported |
| Multilingual support | EN, CN, DE, FR, IT, ES, RU, JP |
| Machine weight | 24 kg |
| Package weight | 28.5 kg |
| Product dimensions | 425 x 362 x 652 mm |
| Packaging dimensions | 785 x 520 x 490 mm |
Applications for Anycubic Photon Mono M7 Max
- Large resin model printing
- Large prototypes and engineering parts
- Architectural models and design objects
- Batch printing of small parts in one print cycle
- Dental and orthodontic models with suitable resins
- Jewelry master models and casting patterns
- Collectible figures, statues and decorative models
- Housings, mounts, mockups and functional parts
- Production tasks where size, stability and repeatability are important
Compatible materials
Anycubic Photon Mono M7 Max is compatible with 405 nm photopolymer resins. Standard Resin and Standard Resin V2 are suitable for everyday printing. ABS Like Resin, ABS Like Resin V2, ABS Like Resin Pro 2 and Tough Resin are better for stronger models. High Speed Resin is recommended for faster printing. Water Wash Resin can be used for easier cleaning. Plant Based Resin is suitable for lower odor printing.
- Standard Resin
- Standard Resin V2
- High Speed Resin
- High Speed Resin 2.0
- Water Wash Resin
- Water Wash Resin Plus
- ABS Like Resin
- ABS Like Resin V2
- ABS Like Resin Pro 2
- Plant Based Resin
- Tough Resin
- High Clear Resin
- DLP Craftsman Resin
- Bio Resin
Difference between Anycubic Photon Mono M7 Max and Photon Mono M7 Pro
| Parameter | Anycubic Photon Mono M7 Max | Anycubic Photon Mono M7 Pro |
| Screen | 13.6″ 7K | 10.1″ 14K |
| Build volume | 298 x 164 x 300 mm | 223 x 126 x 230 mm |
| Printing volume | 14.7 L | 6.5 L |
| X/Y resolution | 46 x 46 microns | 16.8 x 24.8 microns |
| Release film | Improved ACF Film | Improved ACF Film |
| Leveling | Manual 4 point leveling | Leveling free |
| Main purpose | Large format printing and bigger batches | Higher detail and high speed in medium format |
Usage recommendations
- Mix the photopolymer resin well before printing.
- Complete manual 4 point leveling before the first print.
- Use exposure settings recommended for the selected resin.
- For faster printing, use High Speed Resin and suitable layer height settings.
- Check the condition of the Improved ACF Film and replace it when worn.
- Prevent cured resin residue from remaining on the screen or film.
- Use resin temperature control for stable printing in a cold environment.
- After printing, wash the model in alcohol or water depending on the resin type.
- Complete final UV curing after washing.
- Wear gloves and use resin in a well ventilated workspace.
FAQ
What resolution does Anycubic Photon Mono M7 Max have?
The printer has a 13.6″ monochrome LCD screen with 7K resolution.
What is the build volume of Anycubic Photon Mono M7 Max?
The build volume is 298 x 164 x 300 mm and the printing volume is 14.7 L.
What is the X/Y resolution of Photon Mono M7 Max?
The X/Y axis resolution is 46 x 46 microns.
What is the maximum printing speed?
The printing speed is up to 63 mm/h with Standard Resin at 0.1 mm layer height and up to 86 mm/h with High Speed Resin at 0.1 mm layer height.
What release film does the printer use?
Anycubic Photon Mono M7 Max uses Improved ACF Film.
Does the printer support automatic resin feeding?
Yes. The printer supports automatic resin feeding and resin auto recycling management.
Does the printer have resin heating?
Yes. The printer supports dynamic resin vat temperature control from 20 to 40 °C.
Does Anycubic Photon Mono M7 Max require manual leveling?
Yes. The printer uses manual 4 point leveling.
Who is Anycubic Photon Mono M7 Max suitable for?
This model is suitable for users who need a large build volume, stable resin workflow and the ability to print large models or batches of parts.
