Z-axis Synchronous Belt for Anycubic Kobra 2 Plus 400 mm
SKU: S010178
Manufacturer: Anycubic
Compatibility: Anycubic Kobra 2 Plus
Purpose: Z-axis synchronous belt / Z timing belt
Length: 400 mm
Description
The Z-axis synchronous belt for Anycubic Kobra 2 Plus 400 mm is a replacement spare part for the vertical motion system of the FDM 3D printer. The belt supports synchronized Z-axis operation and helps maintain smooth, stable and coordinated vertical gantry movement.
A properly functioning Z-axis belt is important for accurate print geometry, even gantry lifting, a stable first layer and reduced risk of height-related misalignment. Replacement may be required when the belt is worn, stretched, damaged, slipping or after servicing the Z-axis mechanical assembly.
Key Benefits
- Compatible with the Anycubic Kobra 2 Plus 3D printer.
- Designed for the Z-axis assembly.
- Belt length — 400 mm.
- Helps maintain synchronized vertical motion.
- Suitable for repair, maintenance and preventive replacement.
- An important spare part for stable gantry movement and consistent print quality.
Technical Specifications
| Product name | Z-axis Synchronous Belt for Anycubic Kobra 2 Plus 400 mm |
| Alternative name | Z axis synchronous belt / Z timing belt for Kobra 2 Plus |
| SKU | S010178 |
| Manufacturer | Anycubic |
| Part type | Synchronous belt / timing belt |
| Installation axis | Z-axis |
| Length | 400 mm |
| Compatible model | Anycubic Kobra 2 Plus |
| Category | Spare parts for Anycubic FDM 3D printers |
When to Replace the Z-axis Belt
- The gantry becomes misaligned or vertical movement is uneven.
- Cracks, wear, deformation or tooth damage are visible on the belt.
- The belt is stretched, loose or starts slipping.
- Clicking, vibration or unstable mechanics occur during Z-axis movement.
- The original Z-axis motion needs to be restored after disassembly.
- Print defects appear due to unstable vertical movement.
Installation Recommendations
- Turn off the 3D printer and disconnect the power cable before maintenance.
- Secure the gantry so it does not move unexpectedly while servicing the Z-axis assembly.
- Release the old belt tension and carefully remove the belt from the pulleys.
- Install the new belt along the original Z-axis routing path.
- Make sure the toothed side of the belt correctly matches the pulleys.
- Check that the belt is not twisted and runs evenly.
- Adjust belt tension: it should be firm enough for stable movement, but not overtightened.
- After installation, check smooth Z-axis movement and calibrate the printer.
Compatibility
The belt with SKU S010178 is intended for the Anycubic Kobra 2 Plus and the Z-axis assembly. For X/Y axes and other Anycubic Kobra models, select separate belts according to the correct SKU, length and compatibility.
FAQ
Which printer is this belt compatible with?
This belt is intended for the Anycubic Kobra 2 Plus.
Is this a Z-axis belt?
Yes. This is a Z-axis synchronous belt / Z timing belt for Kobra 2 Plus.
What is the belt length?
The belt length is 400 mm.
What is the SKU?
The SKU is S010178.
Can this belt be used instead of the X-axis or Y-axis belt?
No. The X and Y axes use different belts with different lengths and functions. This belt is intended for the Z axis.
Do I need to calibrate the printer after replacement?
Yes. After replacing the Z-axis belt, check gantry movement, belt tension, bed level and run calibration.
