Anycubic ABS-Like Resin 3.0 Gray 1 kg

Anycubic ABS-Like Resin 3.0 Gray is a gray ABS-like photopolymer resin for LCD, MSLA and DLP resin 3D printers. It is designed for strong, accurate and crack-resistant prints with high detail reproduction, low shrinkage, good impact resistance and stable layer curing.

The Gray color is a universal technical shade for engineering prototypes, housings, mock-ups, functional parts, miniatures, architectural models and prints intended for painting. Gray makes surface geometry, relief, fine details and imperfections easier to inspect, making it a practical choice for testing, validation and finishing workflows.

⚙️ Key Benefits

• Gray technical color — convenient for prototypes, mock-ups, functional parts, miniatures and models intended for painting.
• ABS-like strength — suitable for engineering parts, housings, brackets, assembly components and working prototypes.
• High crack resistance — better suited for drilling, sanding, fitting, assembly and mechanical post-processing.
• Low shrinkage of 3.9-4.9% — helps preserve geometry, holes, fitting areas, thin walls and fine features.
• High precision — reproduces relief, textures, sharp edges, thin lines and complex contours.
• Viscosity of 280-300 mPa·s — flows well in the vat and returns to the print area more efficiently.
• 365-405 nm compatibility — suitable for most LCD, MSLA and DLP resin 3D printers.
• Minimal odor according to the product page — uncured liquid resin still requires gloves, eye protection and ventilation.

🧩 Recommended Applications

• gray functional prototypes;
• electronic housings and display covers;
• mechanical assembly parts;
• brackets, holders, adapters and technical components;
• automotive components and mock-up parts;
• architectural and industrial models;
• miniatures, figures, gaming and collectible models;
• master models intended for priming, painting, sanding and finishing;
• parts that require drilling, fitting or testing after printing.

📊 Technical Specifications

Brand	Anycubic
Product Name	Anycubic ABS-Like Resin 3.0 Gray
Type	ABS-like photopolymer resin
Color	Gray
HEX	#7E93A7
Net Weight	1 kg
Pre-print Preparation	Shake well before use
Print Environment	20-40 ℃
First Layer Exposure Duration	23-40 s
Normal Exposure Duration	2-3.6 s
Print Temperature	20-50 ℃
Material	Photopolymer Resin
Wavelength	365-405 nm
Viscosity	280-300 mPa·s at 25 ℃
Density	1.06-1.09 g/cm³
Hardness	83-86 HD
Tensile Strength	38-45 MPa
Elongation at Break	25-30%
Bending Modulus	50-65 MPa
Bending Strength	1500-2000 MPa
Young’s Modulus	1300-1700 MPa
Izod Impact Strength	130 J/m
Volume Shrinkage Rate	3.9-4.9%
Cleaning	95% IPA
Washing Duration	≥3 mins
UV Wavelength	405 nm
Curing Temperature	18-30 ℃
UV Intensity	25000-30000 uW/c㎡
Curing Time	3 mins
Disposal	Post-UV-cured resin is treated as plastic waste

🎨 Gray Color and Palette

Gray is the gray color option of Anycubic ABS-Like Resin 3.0 with the official HEX value #7E93A7. It is a practical color for technical models, prototypes, mock-ups, master models and prints where shape, relief and surface quality need to be clearly visible.

Color	HEX
Gray	#7E93A7
HD Gray	#768692
White	#EFF0F1
Black	#212721
Beige	#FCC89B
Clear	No HEX value
Transparent Green	#009A17
Transparent Blue	#077CAB
Transparent Red	#D22630
Transparent Yellow	#D5BF39
Smoky Black	#688197

✅ Resin 3D Printer Compatibility

Anycubic ABS-Like Resin 3.0 Gray is compatible with LCD, MSLA and DLP 3D printers using photopolymer resin in the 365-405 nm or 405 nm UV curing range. Exposure testing and profile calibration are recommended before production printing.

• Anycubic Photon series: Photon Mono, Photon Mono 2, Photon Mono 4, Photon Mono 4K, Photon Mono 4 Ultra, Photon Mono M5, Photon Mono M5s, Photon Mono M5s Pro, Photon Mono M7, Photon Mono M7 Pro, Photon Mono M7 Max, Photon Mono X, Photon Mono X2, Photon Mono X 6K, Photon Mono X6Ks, Photon M3, Photon M3 Plus, Photon M3 Premium, Photon M3 Max, Photon D2, Photon Ultra.
• Elegoo Mars, Saturn and Jupiter series.
• Phrozen Sonic Mini, Sonic Mighty and Sonic Mega series.
• Creality HALOT ONE, HALOT SKY, HALOT LITE, HALOT MAGE, HALOT MAGE PRO and HALOT R6 series.
• Uniformation GK series, Nova3D, Peopoly and other compatible LCD/MSLA/DLP printers.

Important: this resin is not suitable for FDM/FFF 3D printers because it is a liquid photopolymer, not plastic filament.

⚙️ Recommended Printing Parameters

Printer Model	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Z Lift Distance	Z Lift Speed	Z Retract Speed	Anti-Aliasing Level	Layer Thickness
Photon P1	2 s	2 s	25 s	1	5 mm	3 mm/s	3 mm/s	4	0.05 mm
Photon Mono M7	2.2 s	1 s	35 s	4	8 mm	6 mm/s	6 mm/s	1	0.05 mm
Photon Mono M7 Pro	2 s	1 s	25 s	4	8 mm	6 mm/s	6 mm/s	1	0.05 mm
Photon Mono M7 Max	2 s	0.5 s	30 s	5	8 mm	6 mm/s	6 mm/s	1	0.05 mm
Photon Mono M5	2.8 s	0.5 s	25 s	6	8 mm	6 mm/s	6 mm/s	1	0.05 mm
Photon Mono M5s	3 s	0.5 s	25 s	5	8 mm	6 mm/s	6 mm/s	1	0.05 mm
Photon Mono M5s Pro	3.6 s	1 s	30 s	5	8 mm	6 mm/s	6 mm/s	1	0.05 mm
Photon Mono 4	2.8 s	1 s	30 s	6	6 mm	4 mm/s	6 mm/s	1	0.05 mm
Photon Mono 4K	2 s	0.5 s	40 s	6	6 mm	4 mm/s	6 mm/s	1	0.05 mm
Photon Mono 4 Ultra	2.8 s	1 s	30 s	5	6 mm	4 mm/s	6 mm/s	1	0.05 mm
Photon Mono 2	2.5 s	1 s	28 s	5	6 mm	4 mm/s	6 mm/s	1	0.05 mm
Photon Mono X2	2.5 s	0.5 s	25 s	5	8 mm	2 mm/s	3 mm/s	1	0.05 mm
Photon Mono X 6K	2 s	0.5 s	23 s	6	8 mm	2 mm/s	3 mm/s	1	0.05 mm
Photon Mono X6Ks	2.5 s	0.5 s	20 s	6	8 mm	2 mm/s	3 mm/s	1	0.05 mm
Anycubic Photon M3 Max	3 s	2 s	30 s	6	10 mm	4 mm/s	4 mm/s	1	0.05 mm
Anycubic Photon M3 Premium	2.5 s	0.5 s	25 s	3	8 mm	6 mm/s	6 mm/s	1	0.05 mm

🧼 Printing and Post-Processing

• Shake the bottle well before use.
• Clean the resin vat and build platform.
• Check vat bottom transparency and release film condition.
• After printing, wash the model in 95% IPA for at least 3 mins.
• Dry the model completely before UV post-curing.
• Final UV post-curing: 405 nm, around 3 mins.
• For a cleaner surface, use careful washing, complete drying, proper UV post-curing and finish sanding if required.

🛡️ Safety and Storage

Uncured liquid resin requires careful handling. Use nitrile gloves, eye protection and ventilation. Avoid skin and eye contact. In case of skin contact, wash with soap and water. Do not wipe the skin directly with alcohol. Store the resin tightly closed in a dark, cool and dry place away from children and pets.

📄 File Download: technical files and certificates

• MSDS / SDS — material safety data sheet.
• TDS — technical data sheet.
• REACH — REACH/SVHC report.
• RoHS — restricted substances report.

❓ FAQ



Is Anycubic ABS-Like Resin 3.0 Gray suitable for functional parts?

Yes. It is suitable for functional prototypes, housings, brackets, assembly components and parts that need improved crack and impact resistance.

What is the Gray color best used for?

Gray is suitable for technical parts, prototypes, mock-ups, architectural models, miniatures and prints intended for painting. It makes geometry, relief and surface quality easier to inspect.

What should I use for washing prints?

95% IPA is recommended. After washing, the model should be fully dried and UV post-cured.

Can unused resin be poured back into the bottle?

Yes, but only through a resin filter to remove particles and cured material. Store the resin in a dark, cool and dry place.

Can Gray be mixed with other resins?

Mixing is possible only after testing. When different resins are mixed, exposure settings and mechanical properties should be checked again.
