Description anycubic photon mono x 6k
Anycubic Photon Mono X 6K
Anycubic Photon Mono X 6K is a high precision resin 3D printer with a large build area and a 6K monochrome screen designed for printing large models, functional parts, miniatures, prototypes, master models and decorative items with excellent detail. This model combines a spacious build volume, stable mechanics, a quality optical system and fast exposure performance, making it suitable both for a home workshop and for professional use.
The printer is equipped with a 9.25 inch monochrome LCD screen with a resolution of 5760 x 3600 pixels. This allows it to achieve a high XY accuracy of 34 μm, which is especially important for printing fine details, sharp edges, thin walls, complex geometry and textured surfaces. The large build area of 245 x 197 x 122 mm makes it possible to print multiple parts at once or produce large models without splitting them into sections.
Anycubic Photon Mono X 6K uses a powerful parallel matrix light source based on 40 LED elements. This system provides even light distribution across the entire screen area, improves curing consistency and helps deliver accurate geometry across the build platform. In addition, the printer supports light power adjustment from 30 to 100 percent, which is useful when working with different types of 405 nm photopolymer resin.
A replaceable anti scratch screen protector is included to help protect the LCD screen. This is a practical solution that helps keep the display module in good condition and simplifies maintenance. A printing speed of up to 80 mm per hour allows users to shorten production time, especially when printing batches of smaller parts.
Key advantages of Anycubic Photon Mono X 6K
- Large build area of 245 x 197 x 122 mm
- 9.25 inch 6K monochrome screen
- High XY accuracy of 34 μm
- 5760 x 3600 resolution for crisp detail
- Printing speed up to 80 mm per hour
- Parallel matrix light source with 40 LEDs
- UV light power adjustment from 30 to 100 percent
- Replaceable screen protector above the LCD
- Supports 405 nm resin
- Suitable for workshops, studios, small production and hobby use
Technical specifications
| Printing technology | LCD resin printing |
| Screen | 9.25 inch monochrome LCD |
| Screen resolution | 5760 x 3600 |
| XY accuracy | 34 μm |
| Build area | 245 x 197 x 122 mm |
| Printing speed | up to 80 mm per hour |
| Light source | parallel matrix light source with 40 LEDs |
| Light transmittance | 6 percent |
| Contrast ratio | 350 to 1 |
| Light power adjustment | 30 to 100 percent |
| Interfaces | USB A 2.0, LAN |
| Control panel | 3.5 inch TFT touch control |
| Power supply | 120 W |
| Machine dimensions | 475 x 290 x 270 mm |
| Machine weight | 11 kg |
| Supported resin wavelength | 405 nm |
What Anycubic Photon Mono X 6K is good for
This model is suitable for miniatures, jewelry master models, design objects, enclosure prototypes, souvenir products, decorative elements, engineering parts, dental models when used with the proper resin, and small batch production of detailed components. The large platform is especially useful for users who need both strong detail quality and a generous usable build volume.
Consumables and accessories
Official spare parts and accessories are available for Anycubic Photon Mono X 6K. The official accessories page for this model includes compatible components and maintenance items. For stable operation it is recommended to replace the vat film on time, monitor the condition of the screen protector, clean the build platform regularly and use quality 405 nm photopolymer resin.
- Replacement vat films
- Screen protectors
- Build plates
- Resin vats
- Maintenance tools and consumables
Why choose Anycubic Photon Mono X 6K
Anycubic Photon Mono X 6K is a strong choice for users who need a large resin 3D printer with high resolution and solid printing speed. The model is aimed at users who want to print larger, faster and more accurately than with compact entry level LCD printers. Thanks to its large build area and strong detail performance, this printer works well for commercial use and for serious hobby applications.
Frequently asked questions
What is Anycubic Photon Mono X 6K
It is a resin LCD 3D printer with a large build area, a 6K monochrome screen and high precision for creating detailed resin models.
What is the build area of Anycubic Photon Mono X 6K
The build area is 245 x 197 x 122 mm.
What screen resolution does this model have
The printer uses a screen with a resolution of 5760 x 3600 pixels.
What is the XY printing accuracy
The official XY accuracy is 34 μm.
What type of screen is installed in Photon Mono X 6K
It uses a 9.25 inch monochrome LCD screen.
What is the maximum printing speed
The printing speed is up to 80 mm per hour depending on the model, settings and resin type.
What resins are compatible with this printer
The printer supports 405 nm photopolymer resins. Thanks to adjustable light power it is compatible with standard resin and some special purpose resins.
Can the light source power be adjusted
Yes, the UV light power can be adjusted from 30 to 100 percent.
Does it have screen protection
Yes, a replaceable anti scratch screen protector is included above the LCD screen.
What kind of tasks is this model suitable for
It is suitable for prototyping, miniatures, artistic models, master patterns, decorative pieces and small batch production.
