FEP Film with Frame for Anycubic Photon Mono, Mono 4K, Ultra and D2 173 x 115.4 mm 2 pcs
FEP Film with Frame for Anycubic Photon Mono, Anycubic Photon Mono 4K, Anycubic Photon Ultra and Anycubic Photon D2 is a replacement release film for the resin vat of compatible Anycubic resin 3D printers. The film size is 173 x 115.4 mm, and the package includes 2 pcs.
This FEP film is supplied with a frame, making replacement easier and more accurate. It is installed at the bottom of the resin vat and works as a release layer between the liquid photopolymer resin and the printed model during LCD or DLP resin 3D printing.
Compatibility
- Anycubic Photon Mono
- Anycubic Photon Mono 4K
- Anycubic Photon Ultra
- Anycubic Photon D2
Main advantages
- Compatible with Anycubic Photon Mono, Mono 4K, Ultra and D2
- Film size 173 x 115.4 mm
- Package includes 2 pcs
- Supplied with frame for easier installation
- Designed for resin vat maintenance
- Helps provide stable layer separation during printing
- Suitable for replacing worn, scratched, cloudy or damaged vat film
- Helps reduce the risk of resin leakage when replaced in time
Technical specifications
| Product name | FEP Film with Frame for Anycubic Photon Mono, Mono 4K, Ultra and D2 |
|---|---|
| Compatible models | Anycubic Photon Mono, Photon Mono 4K, Photon Ultra, Photon D2 |
| Film size | 173 x 115.4 mm |
| Film type | FEP release film |
| Design | With frame |
| Quantity | 2 pcs |
| Application | Replacement release film for resin vat |
| Printing technology | LCD and DLP resin 3D printing |
What FEP film is used for
FEP film is one of the most important consumable parts in a resin 3D printer. It is placed at the bottom of the resin vat and allows each cured layer to separate from the vat surface during printing. A clean and correctly installed FEP film helps improve print stability, layer release and surface quality.
If the film becomes scratched, cloudy, punctured, stretched or contaminated with cured resin, the printer may produce failed prints, poor layer separation, surface defects or resin leakage. Regular inspection and timely replacement help protect the vat, LCD screen or optical system and maintain stable printing performance.
Advantages of film with frame
A FEP film with frame is easier to replace than a loose film sheet because the film is already fixed in a framed structure. This helps reduce installation errors, saves maintenance time and improves positioning inside the resin vat.
This option is practical for users who want a fast and clean replacement solution for Anycubic Photon Mono, Photon Mono 4K, Photon Ultra and Photon D2.
When to replace the FEP film
- When deep scratches appear on the film surface
- When the film becomes cloudy in the printing area
- When dents, deformation or stretching are visible
- When resin starts leaking through the vat
- When layers release from the film with difficulty
- When print failures become frequent without changes in settings
- When cured resin remains on the film surface
Installation recommendations
- Turn off the resin 3D printer and remove the resin vat.
- Pour the remaining resin through a filter into a clean container.
- Clean the resin vat carefully with a soft cloth.
- Remove the old framed FEP film from the vat.
- Install the new FEP film with frame in the correct position.
- Check that the frame sits evenly and securely.
- Do not overtighten the fixing elements.
- Before adding resin, make sure the film is clean and undamaged.
- After replacement, check the vat for possible leakage.
Care recommendations
- Do not clean FEP film with sharp metal tools
- Do not press strongly on the film surface
- Remove failed print residues carefully
- Do not allow cured resin to remain on the film
- Check the film before each print for scratches, punctures and cloudy areas
- Use soft cloths and suitable cleaning methods
- Store spare films in a clean and dry place
Difference between FEP, NFEP and ACF
FEP film is a classic release film for resin 3D printing. It is widely used in LCD and DLP resin 3D printers and is suitable for standard printing tasks.
NFEP film usually has lower release force compared with standard FEP film and can improve printing stability for complex models. ACF film is often used for high speed resin printing because it helps reduce layer separation resistance, but it can have different optical and surface properties.
FAQ
Is this FEP film compatible with Anycubic Photon Mono?
Yes. This FEP film with frame is compatible with Anycubic Photon Mono.
Is this film compatible with Anycubic Photon Mono 4K?
Yes. This 173 x 115.4 mm FEP film with frame is suitable for Anycubic Photon Mono 4K.
Is this film compatible with Anycubic Photon Ultra and Photon D2?
Yes. This framed FEP film is compatible with Anycubic Photon Ultra and Anycubic Photon D2.
How many films are included?
The package includes 2 pcs FEP film with frame.
Can I use damaged FEP film?
No. Damaged FEP film should be replaced because resin can leak through punctures or cracks and damage the printer.
Does FEP film affect print quality?
Yes. A clean and correctly installed FEP film helps provide stable layer separation, accurate curing and reliable resin 3D printing.
